产品分类：Micro-Coax Connectors
Technical Specifications:
1. Plug P/N: 20320-R40T-11
2. 0.5mm Pitch, Right Angle Type
3. Number of Position: 30P, 40P, 50P
4. Mating Height: 4.3mm
5. Applicable Cable: Micro Coax AWG#32,#34,#36,#40
6. Rated Voltage: 100V AC
7. Rated Current: 0.3A AC/DC[AWG#40],0.8A AC/DC[AWG#36],1.0A AC/DC[AWG#28-34]
8. Withstand Voltage: AC 250V(rms)
9. Insulation Resistance: Initial 1000MΩ MIN./DC500V; After testing 500MΩ MIN./DC500V
10.Operating Temperature:-40℃ - +85℃
11.Mating Receptacle: I-PEX 20323-R40E-11
