     Technical Specifications:

1. Frequency Range : DC up to 6GHz
    2. VSWR : 1.3MAX at 0.1-3GHz, 1.4MAX at 3-6GHz

3. Characteristic Impedance : 50 ohm ( Nominal )

4. Temperature : -40℃ to +90℃

5. Rated Voltage : AC 60V

6. Contact Resistance : 20m ohm MAX. ( Signal ) and 10m ohm MAX. ( Ground )

7. Withstand Voltage : AC 200V

8. Insulation Resistance : 500M ohm MIN. / DC 100V

9. Packing: 20449-001E, Plastic reel, 10000pcs/reel
